Razor Wire Provides Ultimate Protection for Perimeter Security

Razor wire also known as barbed tape, is a new type of protective netting product with strong protection and isolation capabilities. Designed to prevent unauthorized intrusion along the perimeter barrier.

Razor wire from the hot-dip galvanized steel or stainless steel sheet stamping out sharp blade-shaped, and then wrapped on a high-tensile galvanized steel wire or stainless steel wire core wire to do a combination.

Its sharp blade acts as both a visual and psychological deterrent, making it ideal for industries such as commercial, industrial, residential, and defense.

A section of unrolled razor wire is pulled next to a coil of razor wire

Feature

Aesthetically pleasing design complements the natural beauty.
Galvanized steel or stainless steel construction for corrosion resistant.
Abrasion resistance for long service life.
Sharp blade with multiple profiles has piercing and gripping action, which performs psychological deterrent to intruders.
Enclosed high tensile core wire makes it difficult to cut with standard tools.
Easily installed above or against existing mesh fencing systems.
Compliments our existing range of perimeter security fencing solutions.
Provides much better security compared with traditional barbed wire.
Easy installation and low maintenance.

Specification

Razor wire cross section profile
Material: Stainless steel (304, 304L, 316, 316L, 430), carbon steel.
Surface treatment: Galvanized, PVC coated (green, orange, blue, yellow, etc.), E-coating (electrophoretic coating), powder coating.
Standard wire diameter: 2.5 mm (± 0.10 mm).
Standard blade thickness: 0.5 mm (± 0.10 mm).
Tensile strength: 1400–1600 MPa.
Zinc coating: 90 gsm – 275 gsm.
Coil diameter range: 300 mm – 1500 mm.
Loops per coil: 30–80.
Stretch length range: 4 m – 15 m.

Razor Wire Technical Data
Blade spec	Blade thickness mm	Core wire diameter mm	Blade length mm	Blade width mm	Blade space mm
BTO-10	0.5±0.05	2.5±0.1	10±1	13±1	25±1
BTO-12	0.5±0.05	2.5±0.1	12±1	15±1	26±1
BTO-18	0.5±0.05	2.5±0.1	18±1	15±1	33±1
BTO-22	0.5±0.05	2.5±0.1	22±1	15±1	34±1
BTO-28	0.5±0.05	2.5	28	15	45±1
BTO-30	0.5±0.05	2.5	30	18	45±1
CBT-60	0.6±0.05	2.5±0.1	60±2	32±1	100±2
CBT-65	0.6±0.05	2.5±0.1	65±2	21±1	100±2

Application

Razor wire are widely used in borders, military bases, prisons, airports, government agencies, mines, explosives storage, farms, garden protection, residential areas, factories, railway guardrails, seaports, embassies, reservoirs, oil depots, gardens, substations and other places security protection.
