Double Wire Fence Have More Stable Structure Than Common Welded Wire Fences.

Double wire fence, also known as welded double horizontal wire fence or twin wire fence, is a kind of specially designed welded wire fence with double horizontal wires welded to single vertical wire. Its unique structure makes it stronger and more durable than single wire fence.

Our double wire fence is made of high quality carbon steel wires with a diameter of 6/5/6 mm or 8/6/8 mm. So, the double wire fence is divided into 656 double wire fence and 868 double wire. Typically, our double wire fence cannot come with folds because of its vertical wire is too strong for bending. Besides, galvanized or powder coating treatment gives the double wire fence excellent corrosion and rust resistance performance and a long service life.

Double wire welded fence is very popular in European markets and is widely used in various residential, commercial and industrial applications, including but not limited to, playgrounds, schools, communities, gardens, parks, etc.

Feature

Flat surface, beautiful appearance.
It has both flat top and arch top design patterns for you to choose from.
Double horizontal wires are welded firmly to the vertical wire to form a ridge structure.
Its large mesh opening provides both high visibility and excellent security.
It provides a competitive price while maintaining high quality, rigidity and a long life service.
Its galvanized or powder coating surface give excellent rust & corrosion resistance to withstand various harsh environment conditions.
The galvanized and powder coating treatment allows the double wire fence working properly for nearly 10 years.
It has double horizontal wires to provide more rigidity and durability, so that it will not damage easily and require less maintenance.

Specification

Material: low carbon steel, stainless steel, mild steel.
Surface treatment: galvanized or PVC coated.

galvanized Double Wire Fence Panel

PVC Double Wire Fence Panel
Wire Diameter: 6/5/6 mm, 8/6/8 mm.

656 Double Wire Fence Panel

868 Double Wire Fence Panel
Panel width: 2000 mm, 2500 mm, 3000 mm.
Panel height: 630 mm, 830 mm, 1030 mm, 1230 mm, 1430 mm, 1530 mm, 1630 mm, 1730 mm, 1830 mm, 1930 mm, 2030 mm, 2230 mm, 2430 mm.
Mesh opening: 50 × 100 mm, 50 × 150 mm, 50 × 200 mm, mm, 55 × 200 mm, 75 × 100 mm.
Color: green, white, gray, red, yellow, blue, black.
Accessories: The main components and connection methods of our double wire fence are as shown below.

Clamp Bar Connection

Metal Clamp Connection

J Bolt Connection

U Bolt Connection

Square Clamp Connection

I Post Connection

Application

Double wire fence is widely used in security protection in airports, railways, schools, parks, gardens, farms, yard, private residences, playgrounds, football basketball fields or industrial and other places.
